Timeguard NTM02 - Mounting Details

5. Connection
• The connections are marked as follows;
Live Supply (Brown or Red)
Neutral Supply (Blue or Black)
COM
Normally Open
Normally Closed
Note: this device needs to be left to charge for
a minimum of 15 minutes once powered up,
before it will operate.
6. Mounting Details
62.5 Dia.
3.3 Dia.
60 Sq.
54 CTS
35
21
54 CTS
62.5 Dia.
3.3 Dia.
60 Sq.
54 CTS
35
21
54 CTS
3
1 N L3 2
L
N
1
2
3
