1. General Information
These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the
thermostat is switched off and the circuit supply fuses are removed
or the circuit breaker turned off.
• It is recommended that a qualified electrician is consulted or used for the
installation of this thermostat and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this thermostat is
fitted does not exceed the rating of the circuit cable, fuse or circuit breaker.
• To clean use a clean dry cloth only. Do not use any liquid cleaners.
3. Technical Specifications
Receiver
• 230V AC 50 Hz
• This thermostat is of Class ll Construction and must not be earthed
• Switch Rating: 3(1)A
• Switch Type: Single pole, voltage free
changeover contacts
• Connection Type: 3 wire
• Micro Disconnection: Type 1.B control action
• Illumination: Blue LED illuminated on setting
for button surrounds
• Output Light: Red LED
• Installation Type: Surface mount with wall plate
• CE Compliant
• Dimensions (H x W x D): 90 x 95 x 30mm
