1.3 Specifications
Model 7112 7116
Horsepower Required 20-30 25-35
Working Width 48” 60”
Weight (Lbs.) 391 502
Number of Disc Blades 12 16
Disc Blade Diameter 16”
Disc Blade Spacing 7-1/2”
Bearings Cast
Hitch CAT I
Quick Hitch Compatible Yes
Model 7316 7320 7324
Horsepower Required 30-45 35-50 40-60
Working Width 60” 72” 84”
Weight (Lbs.) 650 700 750
Number of Disc Blades 16 20 24
Disc Blade Diameter 18”
Disc Blade Spacing 7-1/2”
Bearings Sealed
Hitch CAT I
Quick Hitch Compatible Yes
Model 7416 7420 7424
Horsepower Required 35-60 50-70 60-80
Working Width 72” 92” 108”
Weight (Lbs.) 872 1019 1250
Number of Disc Blades 16 20 24
Disc Blade Diameter 20”
Disc Blade Spacing 9”
Bearings Sealed
Hitch CAT l CAT I CAT l & ll
Quick Hitch Compatible Yes
Specications subject to change without notice.
1.4 Intended Usage
Do not use this disc harrow for any other purpose
than its intended use of breaking up the soil surface in
preparation for planting.
1.5 Operator Orientation
The directions left, right, front, and rear, as mentioned
throughout this manual, are as seen from the tractor
operator’s seat and facing in the direction of travel.
1.6 Serial Number Location (Typical)
The serial number decal is located on the front of the
frame.
Model Number ______________________________
Serial Number ______________________________
