What’s in
the box?*
Start
English
4
*Certain parts of the sprayer will not be
assembled out of the box. Be sure to read
Assembly instructions, page 6.
Notice:
This pump is available in a stand model
(100) and cart model (200 shown right).
All information given for the stand model
indicated.
Some of the graphics in this manual may not
All information and instructions given in this
noted.
The type of spray gun and length of spray
hose included depends upon the pump
model you have. Refer to the chart below
for details.
Pump Model Gun Model Hose Length
100 LX-50 25 ft.
200 LX-50 35 ft.
1. Lift the sprayer by the pail
bracket. Lift the leg lock (a) and
unfold the legs (b). Move leg
lock down to lock legs into place.
2. Twist the knob on either side
of the cart toward the “UP”
arrow until it stops.
3. Lift the handle until the motor
housing and handle locks into
place. DO NOT pinch the
power cord with the cart.
4. Insert the ends of the hose
bracket into the holes of the
handle as shown.
To Next Page
