3. Technical data
Weight: 11, 3 kg
Incl. suspension: 11, 7 kg
Dimensions
Without suspension: L = 410 mm
B = 195 mm
H = 220 mm
Incl. suspension: L = 450 mm
H = 300 mm
Tension force: adjustable max. 8000 N
Tensioning speed: 110 mm/sec.
Air pressure: max. 6.0 bar
min. (high-strength quality) 5.0 bar
Air consumtion: 11l/sec. tensioning
6NI sealing
Port for air: G ¼“
Noise emission: 76 db(A)
Hose: min. inside diameter = 8 mm
Sealing: sealing sleeve double notch
Sealing strength: approx. 75 of the Band load at rupture
Type of sleeve: RSK 19 = Band width 19mm
RSK 25 = Band width 25mm
RSK 32 = Band width 32mm
Steel band
Band widths: 19, 25, 32 mm
Standard quality
Band thickness: 0.8–1,0 mm
Tensile strength: up to approx. 900 N/mm²
High-strength quality
Band thickness: 0.8 mm
Tensile strength: up to approx. 1100 N/mm²
