Titan TS142 - Menu 1 Setting Details

Version 2.01 TS132/TS142/TS152 QIG
M4-3
Auxiliary Trunk
wire
(Red/White wire)
Defrost
Drivers Priority
(2
nd
unlock)
Long Trunk
Release (3.5
Seconds)
Normal
Trunk
Release*
M4-4
Auxiliary Sensor
Use
(Only available
on Alarm)
Internal Only External Only
Both Sensors*
³
᧦
´ Indicates factory default setting.
PROGRAMMING MENU SETTING DETAILS:
Note: Bold Settings Indicate Default Setting
MENU 1 EXPLANATION
IGNITION AUTO LOCK
M1-1-1 Flash Door Locks will activate Lock when ignition is turned on for more than
3 seconds and Unlock when the ignition is turned off.
M1-1-2 Flashes Door Locks will only Lock when ignition is turned on.
M1-1-3 Flashes Door lock outputs will not activate with ignition input.
D
OOR UNLOCK/LOCK OPTIONS
M1-2-1 Flash Double Unlock Pulse and Single Lock Pulse (Timing Controlled by M1-3)
M1-2-2 Flashes Single Unlock and Lock pulses. (Timing Controlled by M1-3)
DOOR UNLOCK/LOCK PULSE DURATION
M1-3-1 Flash Door Unlock and Lock Pulses will be ¼ seconds long.
M1-3-2 Flashes Door Unlock and Lock Pulses will be 3 seconds long.
M1-3-3 Flashes Door Unlock pulse will be ¼ second and Door LOCK pulse will be 8
seconds long.
M1-3-4 Flashes Door Unlock and Lock Pulses will be ¾ seconds long.
