In more detail . . .
Engine cold start
1. Set the setting/stop lever (7) to the Start (I) position (Fig. 10).
2. Press the primer (20) until the bubble is lled with fuel (max. 7 times) (Fig. 11).
3. Set the choke lever (22) to the CHOKE position (Fig. 12).
11
20
10
7
12
22
4. Pull the recoil starter handle (19) slowly until you feel a denite resistance and then
give it a brisk, strong pull. Repeat until the engine attempts to start but no more
than 4 times.
5. If the engine does not start, set the choke lever (22) to the RUN position (Fig. 13).
13
22
6. Pull the recoil starter handle (19) slowly until you feel a denite resistance and then
give it a brisk, strong pull. Repeat until the engine starts.
7. Let the engine warm up for 1-2 minutes.
8. To start operation, squeeze the throttle trigger (8) and lock it at the position between
Start (I) and full throttle by the setting/stop lever (7) for the desired working speed.
