Titanium 19000 - Technical Specifications

26
5.2 Technical Specification
Tuner & Demodulator
Frequency Range
950 MHz to 2150 MHz
Input Connector
F-type, IEC 169-24, Female
Signal Level
-25 to -65 dBm
RF Impedance
75Ω¸unbalanced
IF Band width
55 MHz/8Hz(Per 5Msps)
LNB Power &
Vertical : +13 V, 14V +/-5%
Polarization
Horizontal : +18 V, 19V+/-5% Current : 500 mA Max. Overload
Protection
LNB Tone Switch
22KHz+/-2KHz, 0.6Vpp+/-0.2V
DiSEqC Control
Version 1.0/1.2 Compatible, Tone burst A/B
Demodulation
QPSK/8PSK
Symbol Rate
1~45Ms/s/SCPC,MCPC
FEC Decode
Convolution Code Rate 1/2, 2/3, 3/4, 5/6 and 7/8 with Constraint
Length K=7
MPEG
Transport Stream
MPEG-4/H.264, MPEG-2 ISO/IEC 13818
Profile Level
MPEG-4/AVC, MPEG-2 MP@ML, MP@HL
Input Rate
15 Mbit/s Max
Aspect Ratio
4:3, 16:9
Video Resolution
720 x 576, 720 x 480, 1280 x 720, 1920 x 1080
Audio Decoding
MPEG / MusiCam Layer I & II
Audio Mode
Single channel/Dual channel/Joint stereo/Stereo
Sampling
32, 44.1 and 48 KHz
A/V and Data In/Out Connector
TV SCART
RGB, CVBS, L, R out
LNB IF Input
F type, IEC 169-24 Female
LNB IF Output
F type, IEC 169-24 Female
Power Supply
Input Voltage
100 - 240V AC, 50/60Hz,
Power Consumption
Max. 18 W
Standby Power C
3W
Protection
Separate internal fuse. Input shall have lightening Protection
Physical Specification
Weight (Net)
Around 2.0 kg
Operating Temp
0ºC + 40ºC
Storage Temp
-40ºC to + 65ºC
