Sirius iX30
The Sirius iX30 is an versatile and multifunctional card reader with measurements which fits perfectly on
doorposts. Depending on the application, the configuration, and there with the output, can vary.
4.1 Configurations
The configuration defines which card type is read by default by the Sirius iX30.
Functionality
801-5301 TKH coded
801-5302 CSN
801-5303 Programmable
Standard communication
RS485 & Clock/Data
RS485 & Clock/Data
-
Read CSN
No
Yes
-
Read coded TKH cards
Yes
No
-
Output length
8 or 12 digits
10 or 17 digits
-
Reads programable cards
No
No
Yes
Tamper output
Yes
Yes
-
Buzzer input
Yes
Yes
-
LED input
Yes
Yes
-
Default LED settings
Red/Green
Red/Green
Blue
4.1.1 801-5301 TKH coded
The Sirius iX30 TKH coded can both read TKH coded Mifare classic cards and TKH coded Mifare DESFire
cards simultaneously and works by default at the following devices.
Protocol
Hardware device (door controller)
RS485
Orion (stacked)
RS485
Polyx
Clock/Data
Orion (KpBus)
Clock/Data
Orbit
Clock/Data
Third party devices*
*since clock/data is an standard, the Sirius iX30 should work by default on third party controllers which supports
the clock/data communication protocol. We strongly recommend to test it on forehand.
The output differs per card type:
TKH Security Mifare Classic:
• 4 digits system code e.g.: 1234
• 4 digits card number e.g.: 6789
Result as output: 12346789
