TKH security iX30 - 4.1.2 801-5302 CSN; 4.1.3 801-5303 Programmable

8
TKH Security Mifare DESFire:
• 6 digits system code e.g.: 123456
• 6 digits card number e.g.: 789012
Result as output: 123456789012
4.1.2 801-5302 CSN
The Sirius iX30 reads both 4 byte and 7 byte CSN simultaneously and works by default at the following devices:
Protocol
Hardware device (door controller)
RS485
Orion (stacked)
RS485
Polyx
Clock/Data
Orion (KpBus)
Clock/Data
Orbit*
Clock/Data
Third party devices**
*7byte CSN cannot be processed by the Orbit!
**since clock/data is an standard, the Sirius iX30 should work by default on third party controllers which
supports the clock/data communication protocol. We strongly recommend to test it on forehand.
The output differs per card type:
4Byte CSN:
• 10 digits CSN
Result as output: 1234567890
7Byte CSN:
• 17 digits CSN
Result as output: 12345678901234567
4.1.3 801-5303 Programmable
The Sirius iX30 801-5303 programmable does not contain any configuration by default. Programming the Sirius
iX30 depends on the connection/protocol.
Protocol
Hardware device (door controller)
How to program
RS485
Orion (stacked)
Reader configuration file
RS485
Polyx
Reader configuration file
Clock/Data
Orion (KpBus)
Configuration card
Clock/Data
Orbit*
Configuration card
Clock/Data
Third party devices**
Configuration card
