TMT Automation Armstrong - Table of Contents

2
Contents
I. General Safety Warnings
And Precautions 3
II. Product Description And Tended use 4
1. Kit Content ……………………………………………………… 4
2. Dimensions …………………………………………………… 5
III. Installation 6
1. Pre-Installation Checks …………………………………… 6
2. Installation Of The Motors ……………………………… 7-8
IV. Commissioning 9
1. A301U Control Board ……………………………………… 9
2. Motor Wiring ………………………………………………… 10
3. Wiring Of Accessories……………………………………… 10
4. Remote Learning ……………………………………………… 11
5. Photocells ……………………………………………………… 11
6. Safety Device Logic …………………………………………… 12-13
7. Programming ………………………………………………… 14
8. Parameter Table ……………………………………………… 15-20
9. System Learning ……………………………………………… 21
V. Smartphone Control With CHOW! Mobile Application 22
1. Wi-Fi Box WB3 ……………………………………………… 22
2. Quick Set Up Guide ………………………………………… 22-23
VI. Technical Specications 23
