6. INPUT SECTION
6.1. HX-7B and HX-7W
• The2Speakonconnectorsareinternallyconnectedinparalleltothescrewterminals;youcanuseeitherone.
• TherighttableshowsthepinarrangementoftheSpeakonNL4MPconnector.
• Theusableconnector(onthecableend)fortheSpeakonNL4MPisSpeakonNL4FCorNL4FX.
• Wiringdiagramoftheinputconnectorsisshownatright.
• Twospeakersystemscanbeoperatedinparallelbyconnecting
theminacascadecongurationasshownatright.
Note
 Besuretoconnectthespeakersystemtothepoweramplier’s
outputterminalof4Ωorless.
 Connecting it to an output terminal of over 4 Ω may cause
amplierfailure.
PinNo. HX-7B, HX-7W
1 + Speaker +
1 – Speaker –
2 +
–
2 – –
Screw terminal
+
–
Speakon NL4MP x 2
1+
1–
2+
2–
1+
1–
2+
2–
Speaker +
Speaker –
First speaker Second speaker
