Toa M-800RC - Application Examples

41
Office
M-800RC
RE TAI L S TO RE
M-800RM
M-8080D
PC
DA-250FH
9. APPLICATION EXAMPLES
Stock Room
Fitting Room
Sales Floor
F-2000BT / WT
F-2352C
F-2352C
F-2352C
Simple installation with
ambiance control
The 4 zone volumes are
individually controlled from
the office or from the counter
with stereo or mono signals.
A free Soundcard Output of
PC can be connected to
M-8080D to broadcast
Music/Messages/
Advertisement.
The computer can be used
to edit the M-8080D as well.
M-800RCM-822IO
HX-7B / W
F-2000BT / WT
C
C
Music Player
M-800RCT
GYM
M-800RM
M-8080D
M-804EX
DA-250FH
Aerobics Room
Treadmill Room
Lobby
BS-1034W
Flexible sound control
Volume "and presets" can
be controlled from the lobby
by touch panel remote
controller M-800RCT.
In Aerobics Rooms,
instructors can play
dedicated music via
Music player connected
to M-822lO input/output.
Volume is controlled with
a specific M-800RC device.
Locker Rooms 2
Locker Rooms 1


55F
