11. SPECIFICATIONS
11.1. 8x8 DIGITAL MATRIX MIXER M-8080D
Power Source 100-240 V AC, 50/60 Hz
Power Consumption 40 W
Audio Input Input 1 - 8 : -48 to 0 dBV, 6.8 k
Ω
, electronic balanced,
removable terminal block (3 pins x 8)
Audio Output Output 1 - 8 : 0 dBV, 1.8 k
Ω
, Maximum output 20 dBu(7.75V), electronic balanced,
removable terminal block (3 pins x 8)
Over 79 dB (A weighted)
GPI 1 - 2 : no-voltage contact input, open voltage:1.5V DC,
short-circuit current: under 3 mA, RJ45 Connector x 2
Control output
removable terminal block(4 pins)
RD port RD 9 - 12 : transmits and receives AES3 digital audio plus control data
and M-800RM, maximum cable length is 100 meters, RJ45 Connector x 2
Threshold: -80 to +20 dB in 1 dB steps
S/N Ratio Over 105 dB (A weighted)
Release: 10 ms - 1 s
Feedback compression
Auto mixer
Threshold: -80 to 0 dB in 1 dB steps
Delay
Depth: -60 to 0 dB in 1 dB steps
Activation: 10 ms - 6 s
Mode: Speech / Music
Filter release: fast / mid / low
FBC type: dynamic Filters / static Filters
Activation: 10 ms - 6 s
Delay time: 0 - 1361.2916 ms
Frequency Response 20 - 20,000 Hz, ±3 dB
Total Harmonic Distortion 0.01 %
Crosstalk
+48 VDC, switchable, Inputs 1 - 8Phantom Power
Control input
Relay 1 - 2 : withstand voltage: 24V DC, control current: Under 500 mA,
connect remote devices such as M-822IO, M-800RC, M-802RC, M-800RCT
Gate
Ratio: 1:1, 1.2:1, 1.3:1, 1.5:1, 1.7:1, 2.0:1, 2.2:1, 2.3:1, 2.5:1, 3.0:1, 3.5:1, 4.0:1, 4.5:1,
Attack: 10 - 150 ms
5.0:1, 5.5:1, 6.0:1, 6.5:1, 7.0:1, 7.5:1, 8.0:1, 8.5:1, 9.0:1, 9.5:1, 10.0:1, gate
Equalizer/Filter 5 band EQ (LPF and HPF) for IN and 8 band EQ (LPF and HPF) for OUT
Parametric Equalizer: 19.7 - 20,160 Hz, range: ±18 dB, Q: 0.4 - 128, Type: peak/low/high
Filter:
High-pass Filter: 19.7 - 20,160 Hz, Type: Butterworth 6, 12, 18, 24, 30, 36, 42, 48 dB;
Bessel 6, 12, 18, 24, 30, 36, 42, 48 dB; Linkwitz 12, 24, 36, 48 dB
Low-pass Filter: 19.7 - 20,160 Hz, Type: Butterworth 6, 12, 18, 24, 30, 36, 42, 48 dB;
Bessel 6, 12, 18, 24, 30, 36, 42, 48 dB; Linkwitz 12, 24, 36, 48 dB
LC-Display
Status: Fault(Red)x1, Comm(Green)x1, Power(Blue)x1
Option
Operating Temperature 0 °C to +40 °C (32 °F to 104 °F)
Operating Humidity 90 % RH or less (no condensation)
Finish Panel: Aluminum, black
Case: Surface-treated steel plate, black, paint
Dimensions 483 (W) x 44.2 (H) x 259 (D) mm (19.02" x 1.74" x 10.18")
Weight 4.58 kg
Accessory Power cord (2 m)...2, CAT5 cable (2 m)...1,
Removable terminal block(4 pins)...1, Removable terminal block(3 pins)...17
M-804EX, M-822IO, M-800RC, M-802RC, M-800RCT, M-800RM
Display
Displays device information: name, firmware version, ID, communication status
Indicators
Output: Analog Signal(Green)x8, Analog Peak(Red)x8, RD Signal(Green)x4, RD Peak(Red)x4
Input: Analog Signal(Green)x8, Analog Peak(Red)x8, RD Signal(Green)x4, RD Peak(Red)x4
Compressor Threshold: -30 to +20 dB in 1 dB steps
Release: 10 ms - 1 s
Ratio: 1:1, 1.2:1, 1.3:1, 1.5:1, 1.7:1, 2.0:1, 2.2:1, 2.3:1, 2.5:1, 3.0:1, 3.5:1, 4.0:1, 4.5:1,
Attack: 10 - 150 ms
5.0:1, 5.5:1, 6.0:1, 6.5:1, 7.0:1, 7.5:1, 8.0:1, 8.5:1, 9.0:1, 9.5:1, 10.0:1, limit
Level: 0-15Ducker
(FBC)
A/D Converter 24 bit
Sampling Frequency 48 kHz
