Toa M-800RC - Page 45

No.
Start
Byte0
(1Byte)
Start
Byte1
(1Byte)
Start
Byte2
(1Byte)
Length
(2 byte)
Device
(2Byte)
D Address
(high Byte)
ID Address
(Low Byte)
Type
(2Byte)
Command
(2Byte)
Channel Local Channel: 0x01 - 0x0C
(n Byte) Network Channel: 0x0D - 0x14
Value
(n Byte)
End Byte
(1Byte)
Function
13 0x01 0x20 0x03
0x00
0x23
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x0A
Matrix Output Channel: 0x01-0x14
(1Byte)
Matrix Local Input 1: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 2: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 3: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 4: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 5: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 6: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 7: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 8: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 9: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 10: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 11: 0x00-Off, 0x01-On (1Byte)
Matrix Local Input 12: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 1: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 2: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 3: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 4: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 5: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 6: 0x00-Off, 0x01-On (1Byte)
Matrix Network Input 7: 0x00-Off, 0x01-On (1Byte)
0x40 Receive Matrix Mixer Status
14 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x0B
Channel 1-12 : 0x01–0x0C
(1 Byte)
Invalid: 0x00 (1Byte) 0x40 Input Gain Up, Step=1dB
15 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x0C
Channel 1-12 : 0x01–0x0C
(1 Byte)
Invalid: 0x00 (1Byte) 0x40 Input Gain Down, Step=1dB
16 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x0D
Channel 1-12 : 0x01–0x0C
(1 Byte)
Invalid: 0x00 (1Byte) 0x40 Output Gain Up, Step=1dB
17 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x0E
Channel 1-12 : 0x01–0x0C
(1 Byte)
Invalid: 0x00 (1Byte) 0x40 output Gain Down, Step=1dB
18 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x0F
Channel 1-12 : 0x01–0x0C
(1 Byte)
DC-48V: 0x00-Off, 0x01-On (1Byte) 0x40 Input DC-48V
19 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x10 Relay 1 / Relay 2: 0x01/0x02 (1Byte) Relay Channel 1-None: 0x00-0x09 0x40 Relay Control
20 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x11 Invalid: 0x00 (1Byte) Invalid: 0x00 (1Byte) 0x40 Get Relay Status
21 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x11
Relay 01 Channel 1-None: 0x00-0x09
(1Byte)
Relay 02 Channel 1-None: 0x00-0x09 0x40 Receive Relay Status
22 0x01 0x20 0x03
0x00
0x1F
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x12
16 Chars Device Name -ASCILL Code
(16Byte)
Invalid: 0x00 (1Byte) 0x40 Modify Device Name
23 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x13 Invalid: 0x00 (1Byte) Invalid: 0x00 (1Byte) 0x40 Get Devie Information
24 0x01 0x20 0x03
0x00
0x1F
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x13
16 Chars Device Name -ASCILL Code
(16Byte)
Firmware Version: 0x10-0x99 0x40 Receive Device Information
25 0x01 0x20 0x03
0x00
0x10
0x00
0x06
0x01 (High
Byte of ID
address)
0x00 (Low
Byte of ID
address)
0xA5 0xE8 0x00 0x14 Preset number: 0x01-0x18 (1Byte) Invalid: 0x00 (1Byte) 0x40 Recall Preset
NOTE: RS232 Buadrate == 9600
ID address, example: If ID==0x100 then High Byte of ID address=0x01 and Low Byte of ID address=0x00
