Toa M-800RC - Remote Audio Control Panel with Audio out M-802 Rc; Remote Audio Input Output Panel M-822 Io

47
11.4. REMOTE AUDIO CONTROL PANEL WITH AUDIO OUT M-802RC
11.5. REMOTE AUDIO INPUT OUTPUT PANEL M-822IO
Power Source 24V DC (Powered by M-8080D or M-804EX)
Displays device information : ID, Volume, communication status
Operating Temperature 0 °C to +40 °C (32 °F to 104 °F)
Operating Humidity 90% RH or less (no condensation)
Control Volume / routing
Display LC-Display
RD IN Transmits and receives AES3 digital audio plus control data
Connect to M-8080D or M-804EX, RJ45
connector
A
udio Output Line output 1 - 2 : 0 dBV, 1.8 k
Ω,
Maximum output 20 dBu (7.75 V) ,
e
lectronic balanced, screw terminal (3 pins x 2)
Finish
Dimensions 147 (W) x 86 (H) x 65 (D) mm (5.79" x 3.39" x 2.56")
Weight 0.3 kg
Accessory
Over 79 dB (A weighted)
S/N Ratio Over 105 dB (A weighted)
Frequency Response 20 - 20,000 Hz, ±3 dB
Total Harmonic Distortion 0.01 %
Crosstalk
Model no. M-802RC M-802RCB
Panel: Polycarbonate + ABS,
Front cover...1, Wall mounting screw (4 x 30)...4, Box mounting screw (4 x 20)...4,
white (RAL9016 or equivalent)
Panel: Polycarbonate + ABS, black
Plastic anchor...4
Power Source 24V DC (Powered by M-8080D or M-804EX)
Line input A - B : 0 dBV, 5.1 k
Ω
, unbalanced, RCA pin jack
O
ver 79 dB (A weighted)
S/N Ratio Over 105 dB (A weighted)
Operating Temperature 0 °C to +40 °C (32 °F to 104 °F)
Operating Humidity 90 % RH or less (no condensation)
Finish
Dimensions 147 (W) x 86 (H) x 52 (D) mm (5.79" x 3.39" x 2.05")
Weight 0.3 kg
Accessory
Frequency Response 20 - 20,000 Hz, ±3 dB
Total Harmonic Distortion 0.01 %
Crosstalk
+48 VDC, switchable, MIC inputPhantom Power
Indicators
Output: Signal (Green) x 2, Peak (Red) x 2
Input: Signal (Green) x 2, Peak (Red) x 2
Audio Input MIC input : -48 dBV, 5.1 k
Ω
, electronic balanced, XLR connector
A
udio Output Line output 1 - 2 : 0 dBV, 1.8 k , maximum output 20 dBu (7.75 V) ,
electronic balanced, screw terminal (3 pins x 2)
RD IN Transmits and receives AES3 digital audio plus control data
connect to M-8080D or M-804EX, RJ45 connector
Model no. M-822IO M-822IOB
Panel: Polycarbonate + ABS,
Front cover...1, Wall mounting screw (4 x 30)...4, Box mounting screw (4 x 20)...4,
white (RAL9016 or equivalent)
Panel: Polycarbonate + ABS, black
Plastic anchor...4
24 bit A/D Converter
48 kHz Sampling Frequency
