48
11.6. REMOTE AUDIO CONTROL PANEL WITH TOUCH DISPLAY M-800RCT
11.7. EXTENSION MODULE 4 PORTS M-804EX
Power Source 24V DC (Powered by M-8080D or DC24V external power supply)
RD in(Green) x 1, RD exp audio(Green) x 1, RD exp control(Green) x 3, Power(Red) x 1
Operating Temperature 0 °C to +40 °C (32 °F to 104 °F)
Operating Humidity 90 % RH or less (no condensation)
Finish Panel: Aluminum, black
Dimensions 196.2 (W) x 44.2 (H) x 133 (D) mm (7.72" x 1.74" x 5.24")
Weight 0.92 kg
Accessory Removable terminal plug(2p)...1, CAT.5e cable(2m)...1, Plastic foot pad...4
RD IN
RD EXP Port 1: transmits and receives AES3 digital audio plus control data
connect to M-822IO, M-800RC, M-802RC, M-800RCT or M-800RM, RJ45 Connector
Transmits and receives AES3 digital audio plus control data
Connect to M-8080D, RJ45 Connector
Indicators
Port 2-4: transmits and receives control data
connect to M-800RC or M-800RCT, RJ45 Connector
Case: Surface-treated steel plate, black, paint
maximum cable length 100 meters in total from M-8080D RD port to last controller
maximum cable length 100 meters in total from M-8080D RD port to last controller
Power Source 24V DC (Powered by M-8080D or M-804EX)
Displays device information : ID, Volume, preset, communication status, system, etc.
Operating Temperature 0° C to +40 °C (32 °F to 104 °F)
Operating Humidity 90% RH or less (no condensation)
Display LC-Display
RD EXP Transmits and receives control data
Connect to M-800RC or M-800RCT, RJ45 Connector
Finish
Dimensions 150 (W) x 115 (H) x 28 (D) mm (5.90" x 4.53" x 1.10")
Weight 0.28 kg
Accessory Wall mounting screw (4 x 30)...4, Box mounting screw (4 x 20)...4, Plastic anchor...4
RD IN Transmits and receives AES3 digital audio plus control data
Connect to M-8080D, M-804EX or M-800RC, M-800RCT for daisy chain, RJ45 Connector
Model no. M-800RCT M-800RCTB
Panel: Polycarbonate + ABS,
white (RAL9016 or equivalent)
Panel: Polycarbonate + ABS, black
