6.2.2. Connection to 4 Ω output (unbalanced direct output)
DIRECT
4Ω 8Ω
70V
25V
COM
70V
25V
8Ω
COM
OT IN
4Ω
• P-906MK2, P-912MK2
• P-924MK2
4 Ω
4 Ω
Step 1. Loosen the screw.
Step 2. Shift the impedance selector switch to "4 Ω" position.
Step 3. Retighten the screw.
Remove the jumper strip.
