TOHATSU MFS 15 Owner's Manual

1-6
Service Information
4st 9.9/15/20 2008
3) Special Tools
Measuring compression
pressure
Removing/installing flywheel
Measuring engine revolution
speed
Compression Gauge
P/N. 3AC-99030-0
Flywheel Puller Kit
P/N. 369-72211-0
Tachometer
P/N. 3AC-99010-0
Spring Pin Tool A
P/N. 345-72227-0
Removing spring pin
Spring Pin Tool B
P/N. 345-72228-0
Installing spring pin
Inspecting pressure
Vacuum/Pressure Gauge
P/N. 3AC-99020-0
3
A
C
-
7
2
8
7
1
-
0
Piston Slider
P/N. 3AC-72871-0
Installing piston
Removing/installing Pinion (B) Gear Nut
Bevel Gear B Nut Wrench
P/N. 346-72231-0
Bevel Gear B Nut Socket
P/N. 346-72232-0
Installing forward (A) gear
bearing
Bevel Gear Bearing Installation Tool
P/N. 346-72719-0
Removing forward (A) gear
bearing outer race
Bevel Gear Bearing Puller Ass'y
P/N. 3A3-72755-0
Measuring gaps
Thickness Gauge
P/N. 353-72251-0
Installing/attaching drive shaft housing
Needle bearing press Ass'y
P/N. 3AC-72764-0
Needle Bearing Press Bolt
(3C7-72766-0)
Needle Bearing Press Rod
(3BJ-72767-0)
Bearing outer press guide
(3BJ-72765-0)
Bolt M8-110 (910194-0690)
Washer (940191-0600)
Needle Bearing Press Collar
(3AC-72768-0)
Needle Bearing Press Flange
(3BJ-72901-0)
Needle Bearing Press
(3BJ-72770-0)
O ring (176-32545-0)
Needlerollerforfacetomark
"G" mark
"G" mark
Stopper
G
G
Needle Bearing Press Guide
(3BJ-72905-0)
E_MFS20C_ch01_090105.qxd 09.1.20 5:09 PM ページ 6
