TOHATSU MFS 25C User Manual

SPECIFICATIONS 13
2
ENOM00013-0
Remark: Specifications subject to change without notice.
*1 Type I is conventional multi function tiller handle. Type II is equipped with a PTT switch on the end of throttle
grip.
*2 With propeller
*3 With Manual Start
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
MF, E
Item MODEL
25C/30C
MF
E
(with multi-
function tiller
handle)
E
(with RC)
Overall Length mm (in) 1038 (40.9)
type I: 1303 (52.3)
type II: 1353 (53.3)*1
726 (28.6)
Overall Width mm (in) 411 (16.2)
Overall Height S·L mm (in) 1189(46.8) 1337 (52.6)
Transom Height S·L mm (in) 404 (15.9) 552 (21.7)
Weight*2
S kg (lb) 71.5 (158) 77.0 (170) 73 (161)
L kg (lb) 73 (161) 78.5 (173) 74.5 (164)
Output kW (ps) 25B : 18.4 (25) 30B : 22.1 (30)
Max. Operating Range min
-1
(rpm) 25B : 5000–6000 30B : 5250–6250
Idle Speed min
-1
(rpm) 850 ±30
Engine Type 4-Stroke fuel injecton
Number of Cylinder 3
Bore × Stroke mm (in) 61 × 60 (2.40 × 2.36)
Piston Displacement cm
3
(Cu in) 526 (32.09)
Exhaust System Through hub exhaust
Cooling System Water cooling
Engine Lubrication Trochoid pump
Starting System Manual Electric starter motor*3
Ignition System Flywheel Magneto C.D. ignition
Spark Plug NGK DCPR6E
Alternator 12V 120W 15A
Trim Position 6
Engine Oil mL (qt.) API SF, SG, SH or SJ, SAE 10W-30 Approx. 1800 (1.9)
Gear Oil mL (fl.oz.) Genuine Gear Oil or API GL5,SAE #80-90, Approx. 360 (12.2)
Fuel Unleaded Regular Gasoline : R+M/2: 87 or higher RON: 91 or higher
Fuel Tank Capacity L (US gal) 25 (6.60)
Gear Reduction Ratio 2.17 (12 : 26)
Emission Control System MFI (Multiport Fuel Injection)
Operator Sound Pressure
(ICOMIA 39/94) dB (A)
80.4
Hand Vibration Level
(ICOMIA 38/94) m/sec2
2.8 —
