ENGINE OPERATION 37
7
otherwise fuel spillage may occur when the
connector is connected to the engine.
Do not connect fuel connector except when
operating engine. Fuel leakage is a fire or
explosion hazard, which can cause serious
injury or death.
1. Full open the air vent screw on the
fuel tank cap.
1. Air vent screw
2. Fuel tank cap
2. Loosen the tank cap until it contacts
the tab lock and release internal
pressure completely. After that, close
the tank cap until two clicks sound is
heard.
3. Connect the fuel connector to the
engine and fuel tank.
1. Fuel connector
2. Push
3. Insert
1. Pull
2. Insert
4. Squeeze primer bulb until it becomes
stiff to feed fuel to vapor separator.
Direct arrow mark upward when
priming.
1. Engine side
2. Fuel tank side
Do not squeeze primer bulb with engine
running or when the outboard motor is
ENOF00036-0
1
2
ENOF00029-0
ENOF01109-A
1
2
2
2
3
3
1
2
ENOF00861-A
1
2
ENOF00862-0
