PRE-OPERATING PREPARATIONS32
6
ENOM00039-0
If outboard motor encounters an abnormal
condition of fault, the warning horn will
emit a continuous beep or intermittent
short beeps and the warning lamp (LED)
will synchronize with the horn and engine
speed will be limited (engine will not be
stopped).
See next page for conditions which will
lead to an abnormal condition or fault.
ENOM00040-C
Location of warning horn and
lamp
Warning horn
RC model (EPT type): Located inside the
remote control.
*No horn is located for tiller handle type
and EP type.
Warning lamp (LED)
RC model: Located in the tachometer &
bottom cowl.
Tiller handle models: Located on the bot-
tom cowl.
ENON00009-A
Note
Warning lamp for optional tachometer will
synchronize with the waring lamp for engine
side.
1. Warning lamp
1. Warning lamp
5. Warning system
1
ENOF00851-A
To Next Page
