INSPECTION AND MAINTENANCE 73
10
ENOM00088-A
Anode replacement
A sacrificial anode protects the outboard motor from electrolytic corrosion. Anode is
located on the gear case, cylinder etc.. When the anode is eroded more than 1/3 of origi-
nal size, replace it.
ENON00029-0
Notes
Never grease or paint the anode.
At each inspection re-tighten the anode attaching bolt. As it is likely to be subjected to electrolytic
corrosion.
*1 : Only for Power tilt model
*2 : Remove CD unit to access the anode.
To Next Page
