Page 2-4 Document Ref 942005-001 Rev 2.2
TQP-HS for Fuel Dispensers Component Technical Manual
Suction capacity: vacuum pressure dry pump is 350 mbar
vacuum pressure wet pump (with oil) is 700 mbar
Pump intake depth 1.5 to 4 meters depending on installation conditions
Air separator fulfils the EEC regularisation for systems without sight glass
Filters 12 or 25 μm paper mesh and 90 μm plastic mesh (can be cleaned
and re-used). The filter can easily be replaced without spillage,
and without losing the priming on the suction line due to the foot
valve in the bottom of the filter box.
Liquids fuels with a viscosity lower than 10
-4
m
2
/s
Minimum inlet vacuum 300mB @ 80 l/min
for correct operation 300mB @ 130 l/min
2.3 Technical Characteristics
DIMENSIONS
Width x height x length 225 x 450 x 490 mm including motor, filter and mounting
bracket
Weight 37 kg
Suction pipe Ø 1.5 or 2 inches (40 l/min)
Ø 2 inch (80 and 130 l/min)
Inlet of the filter housing DN Ø 40/49 mm (1.5”)
TQP-HS Type Motor power Ø of motor pulley Ø of pump pulley
TQP-HS 80 1 kW / 1400rpm 95 mm 150 mm
TQP-HS 130 1.5 kW / 2800rpm 71 mm 150 mm
HYDRAULIC PERFORMANCES
The hydraulic performance indicators listed below are for a standard installation (i.e. one
pumping unit on the pipeline to the storage tank). The pump has a static lift of 4m, pipe
diameter of 2 inches and pipe length of 40m with a fuel temperature of 20°C.
Flow rate: 40 and 80 l/min (motor of 1 kW) or
130 l/min (motor of 1.5 kW)
Pressure: 1.7 ≤ P ≤ 3.5 bar for TQP-HS 80 l/min
2.3 ≤ P ≤ 3.5 bar for TQP-HS 130 l/min
