Page 1-2 Document Ref 942005-001 Rev 2
TQP-HS for Fuel Dispensers Component Technical Manual
1 INTRODUCTION
1.1 How to Use this Manual
It is recommended that all relevant persons familiarise themselves with the contents of this
manual prior to carrying out any operations or procedures.
This manual is divided into sections which are described as follows: -
Section 1 - Introduction
This section contains information on how to use the manual, the scope of equipment covered,
recommendations on qualified technicians and contact information. It also includes relevant
health and safety information required for the safe installation of the product.
Section 2 - Product Information
This section contains the system descriptions and operating principles of Tokheim’s TQP-
HS pumping unit.
Section 3 - Failure Diagnosis
This section provides the failure diagnosis flow charts for the TQP-HS.
Section 4 - Troubleshooting
This section gives information on troubleshooting problems with the TQP-HS.
Section 5 - Spare Parts & Maintenance Tools
Section 5 lists the assembly drawings and part identification lists for the TQP-HS including
specific tools and maintenance kits.
1.2 Product Scope
This manual is designed to cover the TQP-HS pumping unit in Quantium 10 series dispensers.
1.3 Authorised Technicians
Only qualified technicians familiar with the contents of this manual should carry out the
procedures contained herein.
WARNING : ANY ATTEMPTS TO CARRY OUT THE PROCEDURES OF THIS
MANUAL, BY UNQUALIFIED OR UNAUTHORISED PERSONS, MAY
RESULT IN SERIOUS INJURY OR LOSS OF LIFE.
NOTE : THIS MANUAL IS NOT INTENDED TO REPLACE THE SERVICES
OF A FULLY QUALIFIED TECHNICIAN.
1.4 Contact Information
For information relating to the contents of this manual please contact: -
Technical Author
Tokheim UK Ltd.
Dundee, Scotland
For technical assistance please contact the appropriate service division listed on the back
cover of this manual.
