Batteries
Your Electric Vehicle has two types of batteries:
• High voltage, 100v traction battery.
• Auxiliary 12v battery, identical to the one used in conventional vehicles.
Traction Battery
This battery stores the energy necessary to operate the motor. As with any battery, it dischargers after use and must
be regularly recharged.
The traction battery is equipped with a manual safety disconnect switch to cut the battery power in case of an
emergency or prior to system maintenance.
12-volt Battery
The second battery on your vehicle is a 12v battery. This battery supplies the energy to operate vehicle equipment
(lights, audio etc.) and to start up the system. It is charged while the vehicle is powered on from the traction battery.
High power cables
The high-power circuit is denoted by orange cables, orange with grey stripe wires and parts marked by the
symbol.
