Traction Battery Charging Faults
The standard vehicle charger is equipped with 2 LED light indicating the charger status.
If the LED is blinking red and green and the battery SOC has not reached 95%, there is a connection problem between
the charger and traction battery.
Loose charger plug connection
Make sure charge plug is properly connected
Damaged charge cable or connector
Visually inspect the cable, plug and socket for wear and tear.
Contact manufacturer for replacement if necessary.
Check fuse 14 in traction battery fuse panel. Replace if necessary
Check fuse 21 in traction battery fuse panel. Replace if necessary
DC-DC converter power up failure
Check fuse 15 and relay 5 in traction battery fuse panel.
Replace if necessary
Charger or charge contactor failure
Contact manufacturer for further assistance
