Instrument Panel – EV Display
Error LED
The Error LED will Blink or illuminate constantly whenever a system fault that requires driver’s attention is present.
Not all faults require an immediate stop however all faults require your attention.
LCD
The LCD displays the following information:
1. Accurate traction battery state of charge in percentage from 0% to 100%.
2. Selected driving mode, at standstill.
3. The present error number if an error is present.
The EV display unit is used for SOC display, error messages
and warnings from the main computer on your electric
TOMCAR®.
Driver must pay attention to the display in all times for range
control and system awareness.
5 LED SOC Display
Displays the traction battery state of charge using five LEDs.
Each LED represents approximately 20% of charge.
