Low Voltage Systems
MAINTENANCE
FUSES
RELAYS
Fuse#
Description
Relay#
Description
11
Brake vacuum pump
1
Brake vacuum pump
12
Motor controller cooling system
2
Motor controller cooling system
14
Main lights fuse
4
Main lights relay
15
Brake light
6
Brake light relay
16
Main switch fuse
7
ACC
21
Horn
8
Flasher
22
Parking and license plate lights
23
All in one display back light
24
Low beam
25
High beam
26
ACC
31
Turn signals
34
Switch input to traction battery fuse panel
35
All-in-one display KSI
36
All-in-one display memory
41
Reverse light
42
Air compressor pressure switch input
43
Wipers
46
Cabin power socket + interior light
51
Switch input to Remote control fuse panel
56
Switch input to electric drive switches
