Tomos A31988 - Nuts, Bolts, and Torque Specifications; Special Tools

3
NUTS, BOLTS, AND TORQUE SPECIFICATIONS
Part
Thread
Torque
Spark plug
M14 x 1.25
18Nm
Cylinder cover
M7
12Nm
Flywheel
M10
30Nm
1
st
speed clutch
M10 x 1
25Nm
2
nd
speed driven gear
M14 x 1
80Nm
Mainshaft chain sprocket
M22
60Nm
Cylinder stud bolts
M7
15Nm
Crankcase
M6
10Nm
LH engine cover
M6
6Nm
RH engine cover
M6
7Nm
Engine-frame fastening screws
M8 x 1
25Nm
Swingarm fastening screw
M12 x 1.25
35Nm
Rear shock
M10
25Nm
Top fork lug
M12
35Nm
Front and rear wheel spindle
M11 x 1
32Nm
SPECIAL TOOLS
011.008
Gauge pin
702.856
Crankshaft bearings fitting tool
708.253
Connecting rod bush pulling key
714.011
Repair stand
731.155
Crankshaft bearings puller
731.798
Clutch spring fitting tool
732.193
Dial gauge support tool
732.202
Flywheel and clutch holding tool
732.268
Roller clutch installer
732.746
Iskra flywheel puller
735.753
Fork
735.888
Case splitter
736.533
CEV flywheel puller
737.080
Centering pin
975.709
Dial gauge
