34
7 HANDLING POWER SOURCE
7.1 For removing
1
Push the lock lever downward and pull out the battery.
7.2 Replace the battery (DB-35)
1
Push the hook downward and take the lid out.
2
Take out the old batteries and put new batteries as illustration shows
in direction of plus and minus sides
3
Insert a convex in a upper hole. Click to close the lid by pressing it.
7.3 For installing
Place the base of the battery into the main body, push the battery toward the
instrument side till the battery clicks into position.
● Replace all four batteries to new ones at the same time.
● Do not mix the old batteries to the new ones.
Lock lever
Hook
Lid
Hole
Convex
Lid
