15. SETTING-OUT LINE
84
5. Press [OK] to use the
measurement results of the first
point.
•Press [MEAS] to observe the
first point again.
•Press [HT] to input instrument
and target height.
6. Sight the second point and press
[MEAS].
7. Press [OK] to use the
measurement results of the
second point.
•Press [MEAS] to observe the
second point again.
•Press [HT] to input instrument
and target height.
• Scale factor settings can be set
in the screen shown at right.
8. Press [OK] on the third screen of
step 7 to define the baseline.
<Set-out line> is displayed. Move
to setting-line measurement.
"15.2 Setting-out Line Point"/
"15.3 Setting-out Line Line"
•Press [Sy=1] to set scale factor
y to “1”.
