3. PERFORMANCE & SPECIFICATIONS
3.1 Specifications
Instrument Stand
• Base Size: 25.5 inch x 27.0 inch (648 mm x 686 mm)
• Stand Size: 8.0 inch x 10.0 inch x 34.0 inch
(203 mm x 254 mm x 864 mm)
• Mode of Operation: Continuous Use (Class 1 protection)
Counterbalanced Refractor Arm
• Adjustable Load Range: 8 to 10 lbs (3.6 to 4.5 kg)
• Vertical Adjustment Range: 12 inch (305 mm)
Counterbalanced Slit Lamp Arm
• Adjustable Load Range: 22 to 40 lbs (10 to 18 kg)
• Vertical Adjustment Range: 12 inch (305 mm)
Rechargeable Instrument Wells
• Battery Voltage: 3.5 v
• Charge Rate : Initial: 150 mA
Trickle: 15 mA
Electrical
• Voltage, Current, Frequency:
North America Versions: 120 VAC (± 10%), ~60 Hz, 5A
Export Versions: 240 VAC (± 10%), ~50/60 Hz, 3A
Weight
• Net weight 288 lbs (131 kg)
Environmental Operating Conditions
• Ambient Temperature Range: 50°F to 104°F (10°C to 40°C)
• Relative Humidity Range: 30 to 75%
• Atmospheric Pressure Range: 10.1 to 15.4 psi (700 to 1060 hPa)
Environmental Storage/Transportation Conditions
• Ambient Temperature Range: -22°F to 131°F (-30°C to +55°C)
• Relative Humidity Range: 30 to 95% non-condensing
• Atmospheric Pressure Range: 10.1 to 15.4 psi (700 to 1060 hPa)
• Acceptable Storage Time
(in operating environment): 5 years
(in extreme environment): 20 days
