34
1 NOMENCLATURE AND FUNCTIONS
•
Signal mode
The light acceptance quantity level (Signal level) is displayed in this mode.
When reflected light from the prism is received, a buzzer sounds. This function is good for easy
collimation when the target is difficult to find.
The received return signal level is displayed with bar graph as follows.
•
Reticle illumination
Select the brightness by sliding [UP-DOWN] slider.
The brightness setting is stored in memory after power is turned off.
To turn on or off the reticle illumination, press the [reticle illumination] icon.
[UP-DOWN] slider
[ON]
[OFF]
[UP-DOWN] slider
Reticle illumination icon
Reticle illumination icon
To Next Page
