37
1 NOMENCLATURE AND FUNCTIONS
1.11.2
Setting by Using Star Ke
y
[Example] : Switch on the laser pointer
1
Tu
rn
the power s
witch on.
2
Press the [
] ke
y
.
3
Press the [Laser pointer] icon.
The laser pointer will be tur
ned on.
38
