6.3. HCM1andMainLiftSensorCablingConnections
1. Fasten the 8‐way coupler to the boom with cable ties.Mount flat to the boom or vertically with the
connectorspointingtotheside.Ensuretheconnectorsarenotfacingup.
2. ConnectcableC06betweenthe8‐waycoupler(E11)andthe6‐pinNORACbusconnectoron
theHCM1.

Figure22:NORACBusLocation
3. Connectthemainliftsensorto the8‐waycouplerusingcableC06anda2‐waycoupler(E12).CableC06
anditemE12maynotbeneededifthe8‐waycouplerismountedcloseenoughtothemainliftsensor.
Insertthe6pinplugs(P03)intotheremainingreceptaclesofthe8‐waycoupler.

 
NORACBus
