Nomenclature and Functions
8
Nomenclature and Functions
Remote Controller RC-4R
Emitting window
Panel
Receiving window
Bottom
Battery cover
Serial signal
RS-232C
connector
Rear side
(Laser beam aperture)
Prism unit A7R4
(Optional accessory)
Battery cover lug
Mounting hole
Mounting hole
(small)
Antenna for SS wireless
Sighting collimator
