Basic Operation
15
Setting for Communications with TS/IS/QS
The following settings is prerequisites for the communications to take place between the TS/IS/QS (or an
application program) and RC-4R.
The same RC channel / SS Wireless channel must be assigned to both RC-4R and the TS/IS/QS.
Refer to the TS/IS/QS instruction manual for the TS/IS/QS setup procedures.
Set the parameters in Setting Mode.
Refer to Table of item to be set in Setting Mode.
When connecting the RC-4R and data collector using Bluetooth, there are no settings for the RC-4R. Details
about procedures for connecting the data collector and RC-4R by Bluetooth, refer to the instruction manual for
the application software used on the data collector.
Connect a data collector to be used to the serial RS-232C connector of the RC-4R, and set the items as follows.
Refer to the instruction manual for the application software used on the data collector for the setup procedures.
With RC and SS-Wireless channels for the RC-4R, the parameters of the
application software used for the FC-250 or PC may be prioritized. For further
details, please refer to the instruction manual for your application software.
B.Rate
38400
Data.L
8
Parity
none
Stop Bit
1
