Preparation
13
Communication between the RC-4R and a Data Collector
Bluetooth communication
The Bluetooth module built-in the RC-4R enables wireless-communication with Bluetooth-compatible
equipment.
Serial signal connector
By connecting this connector to a PC or a data collector, it will provide the date transmission.
Mounting Remote Controller Handle Unit RC-4H onto the TS/IS/QS
If you wish to do turn-round motions, attach the remote controller handle unit RC-4H to the TS/IS/QS.
1 Dismount the handle from TS/IS/QS.
2 Match the handle unit mounting marks for the RC-4H and TS/IS/QS.
3 Make sure that the fixing knob is tightly fastened.
Note
Ensure that the power switch of TS/IS/QS is off when mounting RC-4H.
