26
5
When “POS 2” is displayed, rotate the instrument 180 degrees; the instrument will self-
level. When the instrument has auto-leveled, the “POS 2” will stop flashing.
6
Adjust the laser beam to the sensor so that an “on-grade” signals is displayed. To adjust
the position of the laser beam, press the up or down arrows on the panel.
Note
• When rotating the instrument, avoid knocking it off level or changing height.
PRESS ▲ OR ▼
BUTTON TO MOVE
BEAM
X1 laser beam
X2 laser beam
Align Beam to
Fixed Laser
Sensor
50m (160feet)
To Next Page
