25
RL-H3CL
Accuracy : ±2.4mm/50m (±10 ”)
Automatic correction range : ±3°
Beam detecting range : Approx. 2m~500m diameter
(6ft~1640ft)
Rotational speeds : 600r.p.m
Laser source : Laser diode (Visible, Red)
Laser power output : 0.9mW (Max.)
Laser class : Class 2 laser product
Power supply : Four C size alkaline manganese dry batteries
Operating time : Approx. 60 hours at +20°C (+68°F)
Protection against
water and dust : IP56 (Based on the standard IEC60529)
Operating temperature : -20°C~+50°C (-4°F~+122°F)
Dimensions : 167(L)x182(W)x189(H)mm
(6.5x7.1x7.4 in)
Weight : 1.9kg[4.1lbs] (With dry batteries)
LS-70B/70C
Beam detection window : 50mm (2.0 in)
Beam detection precision : High precision : ±1mm(±0.04 in)
: Normal precision : ±2mm(±0.08 in)
Beam detection indication : Liquid crystal and buzzer
Power source : DC 9V alkaline (dry) battery
Operating time : Approx. 80 hours at +20°C (+68°F)
(Using alkaline manganese dry batteries)
Auto shut-off delay : Approx. 30 minutes without beam detection
Operating temperature : -20°C~+50°C (-4°F~+122°F)
Dimensions : 165(L)x78(W)x26(H)mm
(6.5x3.0x1.0 in)
Weight : 0.25 kg [0.55 lbs] (With dry batteries)
