26
RL-H3CS
Accuracy : ±3.6mm/50m (±15 ”)
Automatic correction range : ±5°
Beam detecting range : Approx. 2m~300m diameter (6ft~980ft)
Rotational speeds : 600 r.p.m
Laser source : Laser diode (Visible, Red)
Laser power output : 0.8 mW (Max.)
Laser class : Class 2 laser product
Power supply : Four C size alkaline manganese dry batteries
Operating time : Approx. 60 hours at +20°C (+68°F)
Protection against
water and dust : IP56 (Based on the standard IEC60529)
Operating temperature : -20°C~+50°C (-4°F~+122°F)
Dimensions : 167(L)x182(W)x193(H)mm
(6.5x7.1x7.6 in)
Weight : 1.9 kg[4.1lbs] (With dry batteries)
LS-70B
Beam detection window : 50 mm (2.0 in)
Beam detection precision : High precision : ±1 mm(±0.04 in)
: Normal precision : ±2 mm(±0.08 in)
Beam detection indication : Liquid crystal and buzzer
Power source : DC 9 V alkaline (dry) battery
Operating time : Approx. 80 hours at +20°C (+68°F)
(Using alkaline manganese dry batteries)
Auto shut-off delay : Approx. 30 minutes without beam detection
Operating temperature : -20°C~+50°C (-4°F~+122°F)
Dimensions : 165(L)x78(W)x26(H)mm
(6.5x3.0x1.0 in)
Weight : 0.25 kg [0.55 lbs] (With dry batteries)
