10
Nomenclature and Functions
RL-VH4DR/G2
Handle
Lock button
Lines may appear on the reflector strips.
They are part of normal manufacturing
process and do not effect performance.
Head protector
Laser emitting window
Beam aperture
Control panel
Leveling screw
Battery holder
Battery compartment lock
Rotary head
Magnetic Scanning Target
Magnet
Datum line
Index
Index
Reflectors
The blue target is for RL-VH4G2 and
the red target is for RL-VH4DR.
