Topcon TP-L5GV - 7 Standard Accessories; Self-Centering Feet

43
7. STANDARD ACCESSORIES
Four sets of centering feet are provided with the TP-L5. The feet provided with TP-L5 will center
the laser beam inside the following diameters of pipe:
150mm (6"), 200mm (8"), 250mm (10") and 300mm (12")
They can also be used to set laser on top of the pipe or on a flat surface.
7.1 Self-centering Feet
150mm / 6"
200mm / 8"
250mm / 10"
300mm / 12"
Single point foot
