Topens A5132 - Troubleshooting - Operational Issues; Resolving Running Mode and Gate Movement Problems

30
necessary.
Standby
OFF
Flash(1 Blink every
second)
OFF
Normal (Output Voltage of
the UPS01 is normal)
Running
Flash(1 Blink every
second )
Flash(1 Blink every
second)
Flash(1 Blink
every second)
Normal
Both of the gates do
not move when
operating
OFF
Flash(1 Blink every
second)
OFF
1. Make sure the remote
has been programmed to
the control board before
using.
2. The battery of the
remote may be exhausted.
Replace the battery and try
it again.
3. The control board could
be faulty. Replace the
control board as necessary.
The gate reverse
when on the way of
opening or closing
Flash(1 Blink every
second )
Flash quickly until
the gate stop
running
Flash(1 Blink
every second)
1. Ensure that the gates
swing freely without any
binding.
2. The stall force is
adjusted too small. Turn
the Potentiometer E to
increase the force.
3. Ensure the photo beam
is not blocked when a
photocell is used.
Both of the gates do
not move when
operating
Flash quickly for 3
seconds and then
back to OFF
Flash quickly for 3
seconds and then
back to flash
slowly(1 Blink every
second)
OFF
1. Ensure the photo beam
is not blocked when a
photocell is used.
2. Check if the photocell is
defective or not.
Both of the gates do
not move when
operating
OFF
Flash quickly for 3
seconds and then
back to flash
slowly(1 Blink every
second)
Flash quickly for
3 seconds and
then back to
OFF
Check if the jumper wire
between the EDGE and
GND terminal is loosening
or not.
The gate stop when
on the way of
opening or closing
Flash quickly for 10
seconds and then
back to OFF
Flash quickly for 10
seconds and then
back to flash
slowly(1 Blink every
OFF
Two sequential photo beam
blocked has been detected.
Please ensure the photo
beam is not blocked.
