Single Swing Gate Opener
User’s Manual
Model:
TOPENS Website
www.topens.com
Email: support@topens.com
VER 21c
A3/A5/A8
A3S/A5S/A8S
★ Please read and follow all warnings, precautions and instructions before
installation and use.
★
A 24V 12Ah battery (NOT INCLUDED, 2pcs 12V batteries connected in series may
function as 24V), OR the UPS01 AC-DC Power Supply (NOT INCLUDED) is
REQUIRED to power up this gate opener. The adapter included in the package is
ONLY used to charge the battery.
★
Never connect the solar panel to the control board directly to charge the battery.
★ Periodic checks of the opener are required to ensure safe operation.
★ Save this manual.
C030449

Table of Contents

Questions and Answers

  • M
    Matthew SantiagoAug 6, 2025
    How to fix Topens Gate Opener that opens but doesn't close?
    • S
      Shawna SmithAug 6, 2025
      If your Topens gate opener opens but doesn't close, first check if the connection of the photocell beam is not blocked, assuming a photocell is being used. Also, the closed limit switch might be broken. To check it, remove the BLUE, GREEN, and YELLOW wires of the arm from the control board and use a jumper wire to short the ULT, COM, and DLT terminals; if the arm runs normally, the limit switch is faulty. If neither of these resolves the issue, the control board itself could be faulty and may need replacing.
  • Z
    Zachary SummersAug 10, 2025
    Why Topens A8 automatically opens, but does not automatically close?
    • R
      Renee HawkinsAug 10, 2025
      If your Topens gate opener automatically opens but doesn't automatically close, the setting of DIP switch #1 might be incorrect. Ensure the DIP switch is set correctly according to the push/pull to opener installation of the gate opener.
  • M
    Mrs. Deanna GrayAug 13, 2025
    Why Topens A8 Gate Opener does not respond to the remote control?
    • N
      Nicole HoffmanAug 14, 2025
      If your Topens gate opener isn't responding to the remote, there are several potential reasons. First, ensure the remote has been properly programmed to the control board. If it has, the remote's battery may be dead; try replacing it. Another possibility is a broken limit switch. To test this, remove the BLUE, GREEN, and YELLOW wires from the control board, then use a jumper wire to short the ULT, COM, and DLT terminals. If the arm now runs normally, the limit switch is faulty. Lastly, the control board itself could be faulty and need replacement.
  • T
    Tamara RodriguezAug 18, 2025
    What to do if Topens A8 Gate Opener moves a little and then stops?
    • S
      Steven DaughertyAug 18, 2025
      If your Topens gate moves a little and then reverses or stops, it could be that the selected force is too small to move the gate. Try turning the Potentiometer clockwise to increase the force. Also, disconnect the gate from the gate operator and check that the gate slides freely without any binding.
  • M
    Mark SchwartzAug 22, 2025
    What to do if Topens A8 Power LED does not turn on?
    • B
      Beth HardyAug 22, 2025
      If the Power LED on your Topens gate opener does not turn on, ensure the connection between the battery and control board is correct and fastened. Check the fuse in the control board and replace it if it's burnt out. If the problem persists, the control board itself might be faulty and need replacement.
  • C
    Charles FischerAug 27, 2025
    Why my Topens A8's Power LED flashes rapidly and doesn't run?
    • C
      charlesbowenAug 27, 2025
      If the Power LED on your Topens gate opener flashes rapidly and the opener doesn't run, it's likely due to an over-discharged battery. Check the battery voltage; it should be above 22V for the gate opener to function normally.
  • N
    Nicole McphersonAug 31, 2025
    How to troubleshoot Topens Gate Opener when only the CODE LED is slightly on?
    • K
      Kevin MartinAug 31, 2025
      If your Topens gate opener isn't running and only the CODE LED is slightly on, the batteries may not be connected to the control board, or the wire connection of the batteries is loosened. Note that two 12V batteries are required to power up the gate opener. The adapter included in the package is only for charging the batteries.

Summary

Safety Installation Information

Technical Specifications & Features

Gate Capacity

Installation Overview

Preparation for Installation

Pre-installation steps and considerations before mounting the opener.

Install the Opener on the Gate - for Pull to Open

Install the Opener on the Gate - for Push to Open

Mounting of the Control Box

Connection of the Power Supply

Using Batteries and Solar Panel

Instructions for powering the unit using batteries and a solar panel for charging.

Using UPS01 Uninterrupted Power Supply

Connection of the Control Board

Actuator Connection

Power Source Connections

Wiring power sources (battery, AC-DC, adapter) to specific control board terminals.

How to Program the Remote to the Opener

How to Erase All the Remote Codes

How to Use the Remote to Operate Your Gate Opener

Wireless Keypad Programming

Adjusting the Limit Switch

Setting of the Control Board

Trouble Shooting

Topens A8 Specifications

General IconGeneral
ModelA8
Motor TypeDC Motor
Operating VoltageDC 24V
Protection ClassIP44
Operating Temperature-20°C to +50°C
Control MethodRemote Control
Remote Control RangeUp to 100 ft (30 m)
Safety FeaturesObstacle Detection, Auto Reverse
Max Gate Weight660 lbs (300 kg)
Max Gate Length12 ft (3.66 m)
