Topper WOW RO 50 - Install the Primary Shut-Off Valve

33
For installaon with a standard Primary Shut-O valve (See Figure 14).
A. Shut o the water at the angle stop valve.
B. Use a wrench to loosen the compression nut on the angle-riser tube/ex line to upper faucet.
C. Install the Primary Shut-O valve onto the angle stop. Use the wrench to ghten the compres-
sion nut on the Primary Shut-O valve. Do not overghten.
D. Reconnect the riser tube to the other end of the Primary Shut-O
valve. Do not overghten.
Cauon: A longer riser tube assembly will be required if a gentle
loop cannot be made. (See Figure 13).
E. Fully insert the 1/4” tube into the speed-t/John Guest-style con-
necon. The new incoming water valve can be swiveled to posion
the tubing out of the way.
F. Make sure the Primary Shut-O valve is o before turning the angle
stop valve on. Check for leaks.
Figure 13:
Flexible Hose Posions
Install the Primary Shut-Off Valve
Figure 14: Installaon with Flexible Hoses
Incorrect Correct
