TORK MODEL EW101B / EW103B / EW120B
7 DAY DIGITAL TIME SWITCH
READ INSTR
UCTIONS CAREFULLY BEFORE
ATTEMPTING TO ISTALL TIME SWITCH. SEE WARN-
ING ON FRONT PANEL – Failure to comply with instruc-
tions could result in personal injury and/or property
damage.
INSTALLATION:
UNIT IS TO BE INSTALLED BY A LICENSED ELECTRICIAN
1. To remove unit from enclosure: Push the tab on right
to swing unit the left and remove.
2. Mount the enclosure at eye level using screws or
other suitable fastening device. Bring supply and
load wires in through or side knockouts. DO NOT
USE TOP.
3. Reinstall unit by reversing step #1 above and con-
necting wires to units as per suggested wiring dia-
grams. See illustration and warning on back page.
CAPABILITIES
- 7 Day scheduling.
- ON and OFF set points:
Total # - 20 per day / week
- Minimum setting – 1 minute
- Capable of different schedules each day of the week
FEATURES
Daylight Saving Automatic (can be adjusted).
Leap Year Automatic compensation.
Display LCD
Manual Override Until the next schedule ON or OFF.
Automatic operation then resumes.
Power Outage Permanent schedule retention
Super capacitor maintains real
time up to 4 days.
1
