Tormax Automatic iMotion 1302.KI User Manual

4 Instructions for Use iMotion 1302.KI T-1737 e
<

1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
• Measures for averting danger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these sections can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be reprogrammed
by a specialist.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type: Electromechanical swing door operator with AC permanent magnet
synchronous motor
Control system: iMotion MCU32
Mains connection: 1 x 230 V AC, 10 – 16 A / 1 x 115 V AC, 15 – 20 A, 50 – 60 Hz
Power consumption: 6 … 225 W
Sensor power supply: 24 V DC (+0,5 –1,5 V) 0,75 A
Protective class, drive: IP22
Ambient temperature: –15 °C to +50 °C
Noise emission level: < 70 db (A)

Tormax Automatic iMotion 1302.KI Specifications

General

Brand	Tormax Automatic
Model	iMotion 1302.KI
Category	Door Opening System
Language	English
