8
STORAGE
WHEN CLEANING IS FINISHED:
1. Disconnect the SOLUTION HOSE on the front of the machine by pushing in on the ring of the
solution fitting.
2. Connect the drain hose (clipped to the back) to the SOLUTION HOSE fitting and place the
other end into the RECOVERY TANK (FIG. 3). Press the SOLUTION switch to the “on” position.
This will activate the motor to pump any remaining solution into the RECOVERY TANK for easy
drainage.
3. When all of the solution is pumped from the SOLUTION TANK, turn the SOLUTION switch
off, remove the power plug from the outlet and empty the RECOVERY TANK. Leave the
RECOVERY TANK open when storing.
4. Disconnect the DRAIN HOSE by pushing in on the ring of the SOLUTION HOSE fitting.
Replace the DRAIN HOSE in the clip on the back of the machine, and re-connect the
SOLUTION HOSE.
FIG. 3
GENERAL INSTRUCTIONS
OPERATION INSTRUCTIONS
VACUUM
SWITCH
BRUSH
SWITCH
SOLUTION
SWITCH
FIG. 2
